GEOMEMBRANE

Geomembrane

Model NO.

RH100

Certification

ISO

SurfaceSmooth

ApplicationTransportation Project, Hydraulic Project, Geotechnical Project, Environmental Project

FeaturePuncture Resistance, Impact Resistance, Tear Resistance

MaterialHDPE

ColorBlack

Another NameLandfill Underground Waterproof Membrane

UsageWaterproof Projects

CategoryBlack Smooth HDPE Geomembrane

Thickness0.2mm-5mm

Width0.2-12m

Life Span5-50 Years

Product NameHDPE Geomembrane Pond Liner

KeywordHDPE Geomembrane Waterproof Liner

DescriptionPond Smooth Surface HDPE Liners

Length50m-200m/Roll (as Request)

MOQ500m2

SampleFreely

Transport PackageHDPE Geomembrane Liner Is Packed in The Woven Bags

Specificationthickness: 0.1mm-6mm

TrademarkRUIHENG

OriginChina

HS Code3920109090

Production Capacity50000m2/Day

Online orders

HDPE Geomembrane is made of finest quality high density polyethylene (HDPE) with specially formulated, virgin polyethylene resin, combined with specified quantity carbon black, antioxidant, anti-aging agent and UV resistance components, which makes our smooth geomembrane HDPE Geomembrane with excellent resistance to UV radiation and is suitable for exposed conditions.

Thickness: 0.5mm, 0.75mm,1.0mm,1.5mm,2.0mm
Width: 4m,5m,5.8m,6.0m,7m,8m
Length(roll): 50m 100m 200m 400m

Test		Unit	Standard	Test Frequency	RH75	RH10	RH15	RH20	RH30
Mechanical Properties	Thickness	mm	D5199	per roll	0.75	1.00	1.50	2.00	3.00
	Density	g/cc	D1505/D792	90,000 kg	0.94
	Tensile Properties		D 6693
	· yield strength	kN/m	Type IV	9,000 kg	11	15	22	29	44
	· break strength	kN/m			20	27	40	53	80
	· yield elongation	%			12	12	12	12	12
	· break elongation	%			700	700	700	700	700
	Tear Resistance	N	D 1004	20,000 kg	93	125	187	249	374
	Puncture Resistance	N	D 4833	20,000 kg	240	320	480	640	960
	Stress Crack Resistance	hr.	D 5397	per GRI GM-10	500 hr.
	Carbon Black Content	%	D 4218	9,000 kg	2.0-3.0%
Reference Propertied	Oxidative Induction Time	min	D 3895	90,000 kg	100 min.
	(a) Standard OIT		D 5885		100 min.
	(b) High Pressure OIT				400 min.
	Oven Aging at 85°C retained after 90 days	%	D 5721	per each
	(a) Standard OIT - %		D 3895	formulation	55%
	(b) High Pressure OIT - %		D 5885		80%
	UV Resistance	%		per each
	High Pressure OIT - % retained after 1600 hrs	%	D 5885	formulation	50%
Roll Size	Roll Width	m			7/8	7/8	7/8	7/8	7
	Roll Length	m			280	210	140	105	70
	Size stability	%	2%
